VERTICAL MILLING MACHINE - HU 4VK TOPLINE

Huvema Milling Machine - HU 4VK Topline

Milling machine, Bridgeport type, well finished. Quill with feed. Lubrication system equipped with timer. High quality bearing for high RPM.

• feed on X, Y, Z axis

• drill depth adjustable

• spindle with handbrake

• left/right run

• turning and tilting head

• timer on lubrication system

• variable speed by inverter

• pneumatic  drawbar

-----------------------------------------------

SPECIFICATIONS

Spindle taper                                                                     DIN 2080 ISO 40

Spindle travel                                                                     127 mm

Diameter spindle                                                               100 mm

Speed vertical spindle                                                       5000 vario omw/min

Motor power vertical                                                         3,75 kW

Upper arm ttavel                                                               610 mm

Longitudinal table travel                                                   X - 800, Y - 420, Z - 420 mm

T-slots number/dimensions                                                4 x 16 mm

Milling head tilt forward/backward        45 ° Milling head tilt left/right 90 °

Automatic spindle feed                                                     0,04 - 0,08 - 0,15 mm/omw

Table dimensions l x w                                                   1270 x 254 mm

Dimensions machine l x w x h                                         2000 x 1700 x 2450 mm

Net weight                                                                         1650 kg

Voltage                                                                               400 V
