PORTA DOT 60-30 TOUCH
PORTA DOT 60-30 TOUCH
PORTA DOT 60-30 TOUCH
FEATURES:
- Fully Portable, Lightweight Dot Peen Marking Machine
- 60mm x 30mm marking window
- High Power 36V, quick changeover, battery for deeper marking applications.
- Fully programmable touch screen interface with built-in screen-protector and stylus
- Suitable for engraving identification marks, logos or 2D barcode information
- Can permanently mark most engineering materials up to a maximum hardness of 62Hrc
- Standard Character Sizes: 0.19mm – 59.9mm in increments of 0.19mm (5×7 font) or 0.25mm (7×9 font)
- Dimensions: 295mm(H) x 170mm (W) x 303mm (L)
- Weight: Marking head/battery: 3.7kg
- Drive Mechanism: XY precision lead screws
- Adjustable face mask with horizontal and vertical ‘V’ grooves for tube/pipe marking.
- Dot Mark output styles: 5 x 7,7 x 9,Varidot, 2D Data Matrix, QR Code, HPGL, BMP Logos
- Connectivity options: USB A (USB Flash drive, USB Keyboard), USB B (PC USB-Com Connectivity), WiFi 802.11/b/g/d/h/i/n 2.4GHz (Wireless scanners, data logging, network interfacing)
- MS Excel (*.csv) marking and logging modes.
- Program memory capacity: up to 9000 layouts
- Integrated LED lighting with tilt activation
- On screen mark preview and trial run features
- Rugged carry case
- High Speed Battery Charger: AC Input 50/60Hz; 100-240VAC
