OIL COUNTRY LATHES C800-10T

OIL COUNTRY LATHES C800-10T

Center height400 mm

Swing over bed800 mm

Swing over cross slide560 mm

Swing in gap990 mmWidth of bed560 mm

Distance between centers1500-6000 mm

Taper of main spindleA20-A2.20

Hole through spindle260 mm

Spindle speeds8-400 (12) rpm

Main drive motor11 (15) kW

Number of feeds152

Longitudinal feed range0,02-7,5 mm/r

Number of thread cuttings76

Thread cutting metric0,5-150 mm

Thread cutting Whitworth60-1/5 TPI

Thread cutting module0,125-37,5 Module

Thread cutting pitch240-4/5 DP

Cross slide travel410 mm

Top slide travel150 mm

Tailstock diameter105 mm

Taper tail stockNo 6

Tailstock spindle travel225 mm

Voltage400 VChapterKGroupK11

Family1000-008
