INDUSTRIAL LATHES CU 630X1000 VAC

INDUSTRIAL LATHES CU 630X1000 VAC

Center height315 mm

Swing over bed630 mm

Swing over cross slide430 mm

Swing in gap830 mmWidth of bed500 mm

Distance between centers1000 mm

Taper of main spindleDIN 55027, gr.11

Hole through spindle103 mm

Spindle speeds12,5 - 1250 rpm

Main drive motor11 kW

Number of feeds120

Longitudinal feed range0,04 - 12 mm/r

Cross feed range0,02 - 6 mm

Number of thread cuttings64

Thread cutting metric0,5 - 120 mm

Thread cutting Whitworth0,25 - 60 TPI

Thread cutting module0,125 - 30 Module

Thread cutting pitch1 - 240 DP

Cross slide travel315 mm

Top slide travel130 mm

Tailstock diameter75 mm

Taper tail stockMT5

Tailstock spindle travel250 mm

Voltage400 VChapterKGroupK11

Family1000-002
