Industrial Lathe HU530 x 1500 VAC TOPLINE

Industrial Lathe HU530 x 1500 VAC TOPLINE

Swing over bed530 mm

Swing over cross slide330 mm

Swing in gap740 mmLeadscrew diameter35 mm

Width of bed300 mm

Tailstock diameter68 mm

Distance between centers1500 mm

Center height260 mmHole through spindle80 mm

Taper of main spindleMT7,

CAMLOCK D1-8 (DIN 55029)

Spindle speeds40 - 2000 rpm

Main drive motor7.5 kW

Coolant pump0.1 kW

Longitudinal feed range0,05 - 0,82 mm/r

Cross feed range0,02 - 0,4 mm

Cross slide travel275 mm

Thread cutting metricP 0,5 - P 7 mm

Thread cutting inch4 - 56 TPI

Taper tail stockMT4

Tailstock spindle travel150 mm

Dimensions lxwxh3210 x 810 x 1680 mm

Voltage400 VChapterKGroupK11

Family1000-006
