Industrial Lathe HU480 x 1500

Industrial Lathe HU480 x 1500

Swing over bed470 mm

Swing over cross slide280 mm

Swing in gap690 mm

Leadscrew diameter35 mm

Width of bed300 mm

Tailstock diameter68 mm

Distance between centers1500 mm

Center height235 mm

Hole through spindle80 mm

Taper of main spindleMT7,

CAMLOCK D1-8 (DIN 55029)

Spindle speeds40 - 2000 rpm

Main drive motor7,5 kW

Coolant pump0,1 kW

Longitudinal feed range0,05 - 0,82 mm/r

Cross feed range0,02 - 0,4 mm

Cross slide travel245 mm

Thread cutting metricP 0,5 - P 7 mm

Thread cutting inch4 - 56 TPI

Taper tail stockMT4

Tailstock spindle travel150 mm

Dimensions lxwxh3020 x 810 x 1250 mm

Voltage400 VChapterKGroupK11
